Telemecanique Sensors
Inductive sensor, XS6, M8, stainless steel, Sn 2.5 mm, NPN, NC, M12 connector, L62 mm, 12...48 VDC
Nicht im Verkauf
Telemecanique Sensors XS608B1NBM12, Inductive sensor, XS6, M8, stainless steel, Sn 2.5 mm, NPN, NC, M12 connector, L62 mm, 12...48 VDC. Kategorie: M8 Zylinderform. Nicht im Verkauf; für dieses Produkt gibt es keinen Preis und kein Angebot.
- Referenz:XS608B1NBM12
- Hersteller / Marke:Telemecanique Sensors
Wichtige Eigenschaften
- Range Of Product
- Telemecanique Inductive proximity sensors XS
- Series Name
- General purpose
- Sensor Type
- Inductive proximity sensor
- Sensor Name
- XS6
Produktbeschreibung
Endüktif Sensör Xs6 M8 - U61mm - Paslanmaz - Sn2,5mm - 12..48vdc - M12
Technische Daten
Haupteigenschaften18
| Range Of Product | Telemecanique Inductive proximity sensors XS |
|---|---|
| Series Name | General purpose |
| Sensor Type | Inductive proximity sensor |
| Sensor Name | XS6 |
| Sensor Design | Cylindrical M8 |
| Size | 62 mm |
| Body Type | Fixed |
| Type Of Output Signal | Discrete |
| Wiring Technique | 3-wire |
| Discrete Output Function | 1 NC |
| Detector Flush Mounting Acceptance | Flush mountable |
| Discrete Output Type | NPN |
| Material | Stainless steel |
| Electrical Connection | Male connector M12, 4 pins |
| [Us] Rated Supply Voltage | 12...24 V DC with reverse polarity protection |
| Output Circuit Type | DC |
| Switching Capacity In MA | <= 200 mA DC with overload and short-circuit protection |
| IP Degree Of Protection | IP67 conforming to IEC 60529 |
Ergänzende Eigenschaften14
| Enclosure Material | Stainless steel 303 |
|---|---|
| Detection Face | Frontal |
| Thread Type | M8 x 1 |
| Front Material | PPS |
| Sensing Range | > 0...2.5 mm |
| Differential Travel | 1...15 % of Sr |
| Status LED | Output state: 1 LED (yellow) |
| Switching Frequency | <= 2500 Hz |
| Voltage Drop | <2 V (closed) |
| Current Consumption | <= 10 mA no-load |
| Delay First Up | 10 ms |
| Delay Response | 0.2 ms |
| Marking | CE |
| Delay Recovery | 0.2 ms |
Umgebungsbedingungen3
| Product Certifications | CSA, UL |
|---|---|
| Vibration Resistance | 25 gn amplitude = +/- 2 mm (f = 10-55 Hz) conforming to IEC 60068-2-6 |
| Shock Resistance | 50 gn for 11 ms conforming to IEC 60068-2-27 |
Verpackungseinheiten6
| Unit Type Of Package 1 | piece |
|---|---|
| Number Of Units In Package 1 | 1 |
| Package 1 Height | 4.2 cm |
| Package 1 Width | 9.6 cm |
| Package 1 Length | 6.7 cm |
| Package 1 Weight | 32 g |
Nachhaltigkeit des Angebots1
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
|---|
