Schneider A9L16691 Surge Protection
Not for sale
Schneider A9L16691, Schneider Surge Protection. Category: iPF & iPRD. Not for sale; no price or quote is offered for this product.
- Reference:A9L16691
- Manufacturer / Brand:Schneider
Key Specifications
- Range Of Product
- Acti9
- Product Or Component Type
- Cartridge
- Device Short Name
- C neutral-340
- Surge Arrester Type
- Electrical distribution network
Product Description
The product with reference Schneider A9L16691 is offered originally from our Karaköy central warehouses with the assurance of ÜÇ-EL Elektrik.
Technical Specifications
Main6
| Range Of Product | Acti9 |
|---|---|
| Product Or Component Type | Cartridge |
| Device Short Name | C neutral-340 |
| Surge Arrester Type | Electrical distribution network |
| Standards | IEC 61643-1; EN 61643-11 |
| Product Certifications | OVE; NF; KEMA-KEUR |
Complementary18
| Surge Arrester Class Type | Type 2 |
|---|---|
| Surge Arrester Technology | GDT |
| Earthing System | TN; TT |
| [Ue] Rated Operational Voltage | 230 V AC 50 Hz |
| Nominal Discharge Current | 20 kA |
| Maximum Discharge Current | 65 kA |
| [Uc] Maximum Continuous Operating Voltage | 260 V |
| Maximum [Up] Voltage Protection Level | 1.4 kV type 2 |
| Local Signalling | Flag (white/red) |
| Mounting Mode | Plug-in |
| Mounting Support | Into SPD module |
| 9 Mm Pitches | 2 |
| Height | 50 mm |
| Width | 18 mm |
| Depth | 60 mm |
| Colour | White (RAL 9003) |
| Material | PBT (polybutylene terephthalate) |
| Response Time | < 100 ns |
Environment5
| IP Degree Of Protection | IP20 front face: |
|---|---|
| Relative Humidity | 5…90 % |
| Operating Altitude | 0...2000 m |
| Ambient Air Temperature For Operation | -25…60 °C |
| Ambient Air Temperature For Storage | -40…85 °C |
Packing Units6
| Unit Type Of Package 1 | PCE |
|---|---|
| Number Of Units In Package 1 | 1 |
| Package 1 Height | 7 cm |
| Package 1 Width | 2 cm |
| Package 1 Length | 9 cm |
| Package 1 Weight | 55 g |
Logistical informations1
| Country Of Origin | CN |
|---|
Contractual warranty1
| Warranty (in Months) | 18 |
|---|
