Schneider
TeSys GV3 - auxiliary contact - 1 NO early-break (fault)
Not for sale
Schneider GV3A09, TeSys GV3 - auxiliary contact - 1 NO early-break (fault). Category: TeSys Deca - frame 3. Not for sale; no price or quote is offered for this product.
- Reference:GV3A09
- Manufacturer / Brand:Schneider
Key Specifications
- Range
- TeSys
- Device Short Name
- GV3A
- Product Or Component Type
- Auxiliary contact block
- Product Compatibility
- GV3ME
Product Description
TeSys GV3 - Auxiliary Contact - 1 NO Early Break (fault)
Technical Specifications
Main8
| Range | TeSys |
|---|---|
| Device Short Name | GV3A |
| Product Or Component Type | Auxiliary contact block |
| Product Compatibility | GV3ME |
| Mounting Location | Front side |
| Auxiliary Contacts Operation | Fault signal 1 NO |
| Pole Contact Composition | 1 NO |
| Quantity Per Set | Set of 10 |
Complementary8
| [Ui] Rated Insulation Voltage | 600 V conforming to UL 508; 690 V conforming to IEC 60947-1; 600 V conforming to CSA C22.2 No 14 |
|---|---|
| [Ue] Rated Operational Voltage | 48...690 V AC; 24...220 V DC |
| [Ith] Conventional Free Air Thermal Current | 6 A |
| Mechanical Durability | 1000 cycles |
| Protection Type | GB2CB... circuit breaker; GG fuse 6 A |
| Rated Operational Power In VA | 240 VA at 48 V AC-11 - electrical durability: 1000 cycles; 450 VA at 440 V AC-11 - electrical durability: 1000 cycles; 450 VA at 500 V AC-11 - electrical durability: 1000 cycles; 200 VA at 690 V AC-11 - electrical durability: 1000 cycles; 460 VA at 110…127 V AC-11 - electrical durability: 1000 cycles; 800 VA at 220…240 V AC-11 - electrical durability: 1000 cycles; 850 VA at 380…415 V AC-11 - elect |
| Rated Operational Power In W | 180 W at 24 V DC-11 - electrical durability: 1000 cycles; 180 W at 48 V DC-11 - electrical durability: 1000 cycles; 135 W at 60 V DC-11 - electrical durability: 1000 cycles; 105 W at 110 V DC-11 - electrical durability: 1000 cycles; 90 W at 220 V DC-11 - electrical durability: 1000 cycles |
| Width | 9 mm |
Environment1
| Environmental Characteristic | Normal environment |
|---|
Packing Units6
| Unit Type Of Package 1 | PCE |
|---|---|
| Number Of Units In Package 1 | 1 |
| Package 1 Height | 3.4 cm |
| Package 1 Width | 7 cm |
| Package 1 Length | 7.4 cm |
| Package 1 Weight | 23 g |
Logistical informations1
| Country Of Origin | FR |
|---|
Contractual warranty1
| Warranty (in Months) | 18 |
|---|
