Telemecanique Sensors
XCSA502EX - METAL LIMIT SWITCH NO LOC EX D
Telemecanique Sensors XCSA502EX, METAL LIMIT SWITCH NO LOC EX D. Category: Standard size - up to 70 m. Request a quote for price and lead time.
- Reference:XCSA502EX
- Manufacturer / Brand:Telemecanique Sensors
- Availability:On Request / Inquire Stock
- Price:363.00 EUR (Request a quote)
Key Specifications
- Range Of Product
- Telemecanique Safety switches XCS
- Product Or Component Type
- Safety switch
- Device Short Name
- XCSA
- Material
- Metal
Product Description
Telemecanique Sensors XCSA502EX (METAL LIMIT SWITCH NO LOC EX D). Ask UC-EL Electric for a quote with the current price, stock and delivery details.
Technical Specifications
Main11
| Range Of Product | Telemecanique Safety switches XCS |
|---|---|
| Product Or Component Type | Safety switch |
| Device Short Name | XCSA |
| Material | Metal |
| Head Type | Key operated turret head |
| Electrical Connection | Terminal |
| Clamping Connection Capacity | 1 x 0.5...2 x 1.5 mm² with or without cable end |
| Contacts Type And Composition | 1 NC + 2 NO |
| Contact Operation | Slow-break, break before make |
| Positive Opening | With NC contact |
| Locking Options Description | Without locking of actuator |
Complementary6
| Local Signalling | Without |
|---|---|
| Contact Code Designation | A300, AC-15 (Ue = 120 V, Ie = 6 A) conforming to EN/IEC 60947-5-1, A300, AC-15 (Ue = 240 V, Ie = 3 A) conforming to EN/IEC 60947-5-1, Q300, DC-13 (Ue = 125 V, Ie = 0.55 A) conforming to EN/IEC 60947-5-1, Q300, DC-13 (Ue = 250 V, Ie = 0.27 A) conforming to EN/IEC 60947-5-1 |
| Actuator Force For Extraction | 20 NEWTON |
| Operating Rate | 10 cyc/mn for maximum durability |
| Body Material | Zamak |
| Head Material | Zamak |
Environment12
| Safety Level | Can reach category 4 with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1, can reach PL = e with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1, can reach SIL 3 with the appropriate monitoring system and correctly wired conforming to IEC 61508 |
|---|---|
| Safety Reliability Data | B10d = 5000000 value given for a life time of 20 years limited by mechanical or contact wear |
| Protective Treatment | TC |
| Vibration Resistance | 5 gn (f= 10-500 Hz) conforming to IEC 60068-2-6 |
| Shock Resistance | 10 gn for 11 ms conforming to IEC 60068-2-27 |
| Electrical Shock Protection Class | Class I conforming to EN/IEC 60536 |
| IP Degree Of Protection | IP67 conforming to EN/IEC 60529 and EN/IEC 60947-5-1 |
| Marking | II2 D-Ex tb IIIC T85°C Db IP67 |
| Dust Zone | Zone 21 - 22 |
| Product Certifications | IEC-Ex INE 17.0020X, INERIS 04ATEX0014X |
| Standards | EN/IEC 60079-0, EN/IEC 60079-31 |
| Directives | 2014/34/EU - ATEX directive |
Offer Sustainability1
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
|---|
Packing Units13
| Unit Type Of Package 1 | piece |
|---|---|
| Number Of Units In Package 1 | 1 |
| Package 1 Height | 6.5 cm |
| Package 1 Width | 6.5 cm |
| Package 1 Length | 15.8 cm |
| Package 1 Weight | 0.54 kg |
| Unit Type Of Package 2 | S02 |
| Number Of Units In Package 2 | 12 |
| Package 2 Height | 15 cm |
| Package 2 Width | 30 cm |
| Package 2 Length | 40 cm |
| Package 2 Weight | 6.789 kg |
| Indivisible Sale Quantity | 1 |
