Telemecanique Sensors
Pressure switch, XMP, pressure range 25 bar, adjustable scale, 2NC, G 1/4 female, 2 thresholds
Not for sale
Telemecanique Sensors XMPB25B2131, Pressure switch, XMP, pressure range 25 bar, adjustable scale, 2NC, G 1/4 female, 2 thresholds. Category: XMP series (air and water pressure, 2/3-pole). Not for sale; no price or quote is offered for this product.
- Reference:XMPB25B2131
- Manufacturer / Brand:Telemecanique Sensors
Key Specifications
- Range Of Product
- Telemecanique Pressure sensors XM
- Pressure Sensor Type
- Electromechanical pressure sensor
- Pressure Sensor Name
- XMP
- Fluid Connection Type
- G 1/4 (female) conforming to ISO 228
Product Description
Basınç Sensörü Xmp - 25 Bar - G 1/4 Dişi - 2 Nk- Sıfırlama Düğmesi Kontrolü
Technical Specifications
Main13
| Range Of Product | Telemecanique Pressure sensors XM |
|---|---|
| Pressure Sensor Type | Electromechanical pressure sensor |
| Pressure Sensor Name | XMP |
| Fluid Connection Type | G 1/4 (female) conforming to ISO 228 |
| Controlled Fluid | Air (0-70 °C), fresh water (0-70 °C), sea water (0-70 °C) |
| Cable Entry | 2 entries tapped for Pg 13.5 cable gland conforming to NF C 68-300 |
| Contacts Type And Composition | 2 NC snap action |
| Product Specific Application | Not applicable |
| Pressure Switch Type Of Operation | Regulation between 2 thresholds |
| Electrical Connection | Screw-clamp terminals, clamping capacity: minimum : 2 x 4 mm² |
| Electrical Circuit Type | Power circuit |
| Scale Type | Adjustable differential |
| Local Display | Without |
Complementary11
| Type Of Decompression Valve | Without |
|---|---|
| Control Type | RESET knob |
| Terminal Block Type | 4 terminals |
| Pressure Actuator | Diaphragm |
| Materials In Contact With Fluid | Canvas covered nitrile, chromated zinc alloy |
| Enclosure Material | PA impregnated with fibreglass |
| Operating Position | Any position |
| Operating Rate | 10 cycles/min |
| Resistance Across Terminals | 25 MOhm conforming to IEC 60255-7 category 3, 25 MOhm conforming to NF C 93-050 method A |
| Setting | Nut |
| Terminals Description ISO N°1 | (1-2)NC, (3-4)NC |
Environment6
| Product Certifications | EAC |
|---|---|
| Standards | CE, IEC 60947-4-1 |
| Vibration Resistance | 3 gn conforming to IEC 60068-2-6 (f = 10-500 Hz) |
| Shock Resistance | 50 gn conforming to IEC 60068-2-27 |
| Electrical Shock Protection Class | Class I conforming to IEC 60536 |
| IP Degree Of Protection | IP54 conforming to IEC 60529 |
Packing Units6
| Unit Type Of Package 1 | piece |
|---|---|
| Number Of Units In Package 1 | 1 |
| Package 1 Height | 6 cm |
| Package 1 Width | 11.5 cm |
| Package 1 Length | 17 cm |
| Package 1 Weight | 677 g |
Offer Sustainability1
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
|---|
