Schneider
single foot switch - IP66 - with cover - metallic - orange - 2 NC + 2 NO
Schneider XPER711, single foot switch - IP66 - with cover - metallic - orange - 2 NC + 2 NO. Category: Harmony XPE. Request a quote for price and lead time.
- Reference:XPER711
- Manufacturer / Brand:Schneider
- Availability:On Request / Inquire Stock
- Price:344.00 EUR (Request a quote)
Key Specifications
- Range Of Product
- Harmony XPE
- Product Or Component Type
- Foot switch
- Material
- Metal
- Foot Switch Type
- Single foot switch
Product Description
This Harmony XPER711 is a single foot switch. Its degree of protection is IP66. It has a cover, metallic material, orange color, 2 NC + 2 NO contacts. It is part of the range Harmony XPE foot switches - Control and signaling units for safety applications.
Key Features
- Its degree of protection is IP66
- Complies with RoHS directive relating to environmental protection
- High protection by design
- Wide availability throughout an extensive distribution network
Technical Specifications
Main10
| Range Of Product | Harmony XPE |
|---|---|
| Product Or Component Type | Foot switch |
| Material | Metal |
| Foot Switch Type | Single foot switch |
| Device Short Name | XPER |
| Provided Equipment | Cover |
| Trigger Mechanism | With trigger mechanism |
| Contact Operation | 2 steps |
| Contacts Type And Composition | 2 NC + NO |
| Colour | Orange |
Complementary11
| Positive Opening | With conforming to IEC 60947-5-1 appendix K |
|---|---|
| Connections - Terminals | Screw clamp terminal, <= 1 x 2.5 mm² with or without cable end; Screw clamp terminal, <= 2 x 1.5 mm² with or without cable end |
| Cable Entry | 2 entries tapped for Pg 16 cable gland |
| Mechanical Durability | 15000000 cycles |
| [Ie] Rated Operational Current | 3 A, 240 V, AC-15, A300; 0.27 A, 250 V, DC-13, Q300 conforming to IEC 60947-5-1 appendix A |
| [Ui] Rated Insulation Voltage | 500 V (pollution degree 3) conforming to IEC 60947-1; 500 V (pollution degree 3) conforming to NF C 20-040 group C; 500 V (pollution degree 3) conforming to VDE 0110 group C; 300 V conforming to UL 508; 300 V conforming to CSA C22.2 No 14 |
| [Uimp] Rated Impulse Withstand Voltage | 6 kV conforming to IEC 60947-1 |
| Maximum Resistance Across Terminals | 25 MOhm conforming to IEC 60255-7 category 3; 25 MOhm conforming to NF C 93-050 method A |
| Short-circuit Protection | 10 A cartridge fuse type gG conforming to IEC 60947-5-1; 10 A cartridge fuse type gG conforming to VDE 0660-200 |
| Rated Operational Power In W | 10 W DC-13, operating rate <60 cyc/mn, 5000000 cycles, 24 V, load factor: 0.5 conforming to IEC 60947-5-1 appendix C; 4 W DC-13, operating rate <60 cyc/mn, 5000000 cycles, 120 V, load factor: 0.5 conforming to IEC 60947-5-1 appendix C; 7 W DC-13, operating rate <60 cyc/mn, 5000000 cycles, 48 V, load factor: 0.5 conforming to IEC 60947-5-1 appendix C |
| Net Weight | 2.59 kg |
Environment9
| Standards | NF E 09-031 |
|---|---|
| Product Certifications | FIMKO |
| Protective Treatment | TC |
| Ambient Air Temperature For Operation | -25…70 °C |
| Ambient Air Temperature For Storage | -40…70 °C |
| Vibration Resistance | 15 gn (f= 10…500 Hz) conforming to IEC 60068-2-6 |
| Shock Resistance | 150 gn conforming to NF E 09-031; 20 gn conforming to IEC 60068-2-27 |
| Overvoltage Category | Class I conforming to IEC 61140; Class I conforming to NF C 20-030 |
| IP Degree Of Protection | IP66 conforming to IEC 60529; IP66 conforming to IEC 60529 |
Packing Units12
| Unit Type Of Package 1 | PCE |
|---|---|
| Number Of Units In Package 1 | 1 |
| Package 1 Height | 16.600 cm |
| Package 1 Width | 16.800 cm |
| Package 1 Length | 21.000 cm |
| Package 1 Weight | 2.688 kg |
| Unit Type Of Package 2 | S03 |
| Number Of Units In Package 2 | 2 |
| Package 2 Height | 30 cm |
| Package 2 Width | 30 cm |
| Package 2 Length | 40 cm |
| Package 2 Weight | 5.840 kg |
Logistical informations1
| Country Of Origin | MA |
|---|
Contractual warranty1
| Warranty (in Months) | 18 |
|---|
