Telemecanique Sensors
Inductive sensor, XS9, 40x40x15 mm, Sn 15 mm, PNP, NC, M12 connector, 0.15 m lead, form C flat, 12...24 VDC
Not for sale
Telemecanique Sensors XS9C11RPBL01M12, Inductive sensor, XS9, 40x40x15 mm, Sn 15 mm, PNP, NC, M12 connector, 0.15 m lead, form C flat, 12...24 VDC. Category: Flat format. Not for sale; no price or quote is offered for this product.
- Reference:XS9C11RPBL01M12
- Manufacturer / Brand:Telemecanique Sensors
Key Specifications
- Range Of Product
- Telemecanique Inductive proximity sensors XS
- Series Name
- Application
- Product Or Component Type
- Sensor
- Sensor Type
- Inductive proximity sensor
Product Description
Endüktif Sensör Xs9 - 40x40x15 - Sn15mm - 6..6000c/mn - 12..24vdc - M12 0,15m
Technical Specifications
Main18
| Range Of Product | Telemecanique Inductive proximity sensors XS |
|---|---|
| Series Name | Application |
| Product Or Component Type | Sensor |
| Sensor Type | Inductive proximity sensor |
| Device Application | Rotation monitoring |
| Sensor Name | XS9 |
| Sensor Design | Flat form 40 x 40 x 15 |
| Size | 15 mm |
| Body Type | Fixed |
| Enclosure Material | PBT |
| Type Of Output Signal | Discrete |
| Wiring Technique | 3-wire |
| Discrete Output Function | 1 NC |
| Electrical Connection | Remote male connector M12, 4 pins |
| Discrete Output Type | PNP |
| [Us] Rated Supply Voltage | 12...24 V DC |
| IP Degree Of Protection | IP67 double insulation conforming to IEC 60529 |
| Switching Capacity In MA | <= 200 mA |
Complementary15
| Detector Flush Mounting Acceptance | Flush mountable |
|---|---|
| Material | Plastic |
| Output Circuit Type | DC |
| Detection Face | Frontal |
| Front Material | PBT |
| Repeat Accuracy | <= 3% of Sr |
| Differential Travel | 3...15% of Fr |
| Wire Insulation Material | PVC |
| Sensing Range | 8...15 mm |
| Status LED | Supply on: 1 LED (green), output state: 1 LED (yellow) |
| Switching Frequency | <= 800 Hz |
| Residual Current | 100 mA open state |
| Current Consumption | 0...10 mA no-load |
| Voltage Drop | <2 V (closed) |
| Marking | CE |
Environment3
| Product Certifications | CSA, UL |
|---|---|
| Shock Resistance | 50 gn for 11 ms conforming to IEC 60068-2-27 |
| Vibration Resistance | 25 gn amplitude = +/- 2 mm (f = 10-55 Hz) conforming to IEC 60068-2-6 |
Packing Units12
| Unit Type Of Package 1 | piece |
|---|---|
| Number Of Units In Package 1 | 1 |
| Package 1 Height | 4.2 cm |
| Package 1 Width | 6.6 cm |
| Package 1 Weight | 84 g |
| Package 1 Length | 9.6 cm |
| Unit Type Of Package 2 | S01 |
| Number Of Units In Package 2 | 22 |
| Package 2 Height | 15 cm |
| Package 2 Width | 15 cm |
| Package 2 Length | 40 cm |
| Package 2 Weight | 2.073 kg |
Offer Sustainability1
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
|---|
