Telemecanique Sensors
XSDA400519 - PROXIMITY DETECTOR
Telemecanique Sensors XSDA400519, PROXIMITY DETECTOR. Request a quote for price and lead time.
- Reference:XSDA400519
- Manufacturer / Brand:Telemecanique Sensors
- Availability:On Request / Inquire Stock
- Price:359.00 EUR (Request a quote)
Key Specifications
- Range Of Product
- Telemecanique Inductive proximity sensors XS
- Series Name
- General purpose
- Sensor Type
- Inductive proximity sensor
- Product Specific Application
- Not applicable
Product Description
Telemecanique Sensors XSDA400519 (PROXIMITY DETECTOR). Ask UC-EL Electric for a quote with the current price, stock and delivery details.
Technical Specifications
Main15
| Range Of Product | Telemecanique Inductive proximity sensors XS |
|---|---|
| Series Name | General purpose |
| Sensor Type | Inductive proximity sensor |
| Product Specific Application | Not applicable |
| Sensor Name | XSD |
| Sensor Design | Form 80 x 80 x 40 |
| Size | 40 mm |
| Body Type | Fixed |
| Type Of Output Signal | Discrete |
| Wiring Technique | 2-wire |
| Enclosure Material | Plastic |
| Discrete Output Function | 1 NO or 1 NC programmable |
| Electrical Connection | Screw-clamp terminals |
| [Us] Rated Supply Voltage | 12...240 V AC |
| IP Degree Of Protection | IP67 |
Complementary8
| Detector Flush Mounting Acceptance | Non flush mountable |
|---|---|
| Material | Plastic |
| Output Circuit Type | AC |
| Detection Face | 5 positions turret head |
| Cable Entry | 1 entry tapped for Pg 13.5 cable gland |
| Sensing Range | > 15...40 mm |
| Front Material | Plastic |
| Switching Frequency | <= 10 Hz |
Environment1
| Product Certifications | CCC |
|---|
Offer Sustainability1
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
|---|
Packing Units19
| Unit Type Of Package 1 | piece |
|---|---|
| Number Of Units In Package 1 | 1 |
| Package 1 Height | 5.2 cm |
| Package 1 Width | 8.8 cm |
| Package 1 Length | 14.8 cm |
| Package 1 Weight | 0.498 kg |
| Unit Type Of Package 2 | S02 |
| Number Of Units In Package 2 | 11 |
| Package 2 Height | 15 cm |
| Package 2 Width | 30 cm |
| Package 2 Length | 40 cm |
| Package 2 Weight | 5.727 kg |
| Unit Type Of Package 3 | carton |
| Number Of Units In Package 3 | 1 |
| Package 3 Height | 15.3 cm |
| Package 3 Width | 5.4 cm |
| Package 3 Length | 8.8 cm |
| Package 3 Weight | 0.569 kg |
| Indivisible Sale Quantity | 1 |
