Telemecanique Sensors
XUBLBPCNM12 - CYLINDRICAL METAL LASER THRU-BEAM PHOTO SENSOR
Telemecanique Sensors XUBLBPCNM12, CYLINDRICAL METAL LASER THRU-BEAM PHOTO SENSOR. Category: Compact range. Request a quote for price and lead time.
- Reference:XUBLBPCNM12
- Manufacturer / Brand:Telemecanique Sensors
- Availability:On Request / Inquire Stock
- Price:605.00 EUR (Request a quote)
Key Specifications
- Range Of Product
- Telemecanique Photoelectric sensors XU
- Sensor Name
- XUB
- Series Name
- Application material handling
- Enclosure Material
- Nickel plated brass
Product Description
Telemecanique Sensors XUBLBPCNM12 (PHOTO SENSOR CYLIN METAL LASER THRU BEAM). Ask UC-EL Electric for a quote with the current price, stock and delivery details.
Technical Specifications
Main18
| Range Of Product | Telemecanique Photoelectric sensors XU |
|---|---|
| Sensor Name | XUB |
| Series Name | Application material handling |
| Enclosure Material | Nickel plated brass |
| Electronic Sensor Type | Photo-electric sensor |
| Sensor Design | Cylindrical M18 |
| Material | Metal |
| Electrical Connection | 1 male connector M12 |
| Wiring Technique | 3-wire |
| Detection System | Thru beam |
| Emission | Red laser class 1 670 nm conforming to IEC 825-1 |
| Kit Composition | Transmitter + receiver XUBLBKCNM12T + XUBLBPCNM12 |
| Discrete Output Function | 1 NO or 1 NC programmable |
| [Us] Rated Supply Voltage | 12...24 V DC with reverse polarity protection |
| Type Of Output Signal | Discrete |
| Supply Circuit Type | DC |
| Discrete Output Type | PNP |
| Delay Response | 0.4 ms |
Complementary9
| Setting-up | With sensitivity adjustment |
|---|---|
| Current Consumption | 25 mA no-load |
| Output Type | Solid state |
| Switching Capacity In MA | <= 100 mA (overload and short-circuit protection) |
| Lens Material | PMMA |
| Sensing Range | > 30 m |
| Voltage Drop | <1.5 V (closed state) |
| Delay First Up | 80 ms |
| Delay Recovery | 0.4 ms |
Environment3
| Shock Resistance | 30 gn (duration = 11 ms) conforming to IEC 60068-2-27 |
|---|---|
| IP Degree Of Protection | IP67 conforming to IEC 60529 (double insulation) |
| Vibration Resistance | 7 gn, amplitude = +/- 0.75 mm (f = 10-55 Hz) conforming to IEC 60068-2-6 |
Offer Sustainability1
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
|---|
Packing Units19
| Unit Type Of Package 1 | piece |
|---|---|
| Number Of Units In Package 1 | 1 |
| Package 1 Height | 3.6 cm |
| Package 1 Width | 7 cm |
| Package 1 Length | 13 cm |
| Package 1 Weight | 0.106 kg |
| Unit Type Of Package 2 | S02 |
| Number Of Units In Package 2 | 35 |
| Package 2 Height | 15 cm |
| Package 2 Width | 30 cm |
| Package 2 Length | 40 cm |
| Package 2 Weight | 4.034 kg |
| Unit Type Of Package 3 | carton |
| Number Of Units In Package 3 | 1 |
| Package 3 Height | 13 cm |
| Package 3 Width | 3.6 cm |
| Package 3 Length | 7 cm |
| Package 3 Weight | 0.107 kg |
| Indivisible Sale Quantity | 1 |
