Telemecanique Sensors
XUVU04M3NL02M12 - Application Packaging Transparent Label
Telemecanique Sensors XUVU04M3NL02M12, Application Packaging Transparent Label. Request a quote for price and lead time.
- Reference:XUVU04M3NL02M12
- Manufacturer / Brand:Telemecanique Sensors
- Availability:On Request / Inquire Stock
- Price:666.00 EUR (Request a quote)
Key Specifications
- Range Of Product
- Telemecanique Photoelectric sensors XU
- Sensor Name
- XUV
- Series Name
- Application packaging, LABELLING DETECTION
- Connector Type
- M12
Product Description
Telemecanique Sensors XUVU04M3NL02M12 (UygulamaPaketleme SaydamEtiket). Ask UC-EL Electric for a quote with the current price, stock and delivery details.
Technical Specifications
Main18
| Range Of Product | Telemecanique Photoelectric sensors XU |
|---|---|
| Sensor Name | XUV |
| Series Name | Application packaging, LABELLING DETECTION |
| Product Specific Application | Detection of labels, detection of transparent labels, detection on a labelling machine |
| Connector Type | M12 |
| Enclosure Material | Valox, zamak |
| Electronic Sensor Type | Photo-electric sensor |
| Sensor Design | Fork |
| Material | Valox, zamak |
| Electrical Connection | 1 connector M8, 4 pins |
| Detection System | Through beam |
| Emission | Ultrasonic |
| Discrete Output Function | 1 NO or 1 NC programmable |
| Type Of Output Signal | Discrete |
| Type Of Setting | Teach buttons or IO-Link |
| Supply Circuit Type | DC |
| Discrete Output Type | NPN |
| Delay Response | 0.44 ms |
Complementary14
| Setting-up | Sensitivity by IO-Link, sensitivity adjustment with teach mode |
|---|---|
| Current Consumption | 0.05 mA |
| Output Type | Discrete |
| Switching Capacity In MA | <= 100 mA |
| Add On Output | <= 100 mA with against short-circuits with against reverse polarity |
| Discrete Input Voltage | DC |
| Switching Frequency | 1.1 kHz |
| Accuracy | at 240m/min (for 2 mm label length, 2 mm gap)m/mn |
| Sensing Range | 0 2 7 MM |
| Status LED | 1 LED color: green for power supply 1 LED color: yellow for output status 5 LEDs color: green for output signal |
| Label Length | 2 mm |
| Distance Between Labels | 1 mm |
| Delay First Up | 300 ms |
| Passing Speed Of Object | 4 METER_PER_SECOND |
Environment1
| IP Degree Of Protection | IP65 conforming to EN/IEC 60529 |
|---|
Offer Sustainability1
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
|---|
Packing Units13
| Unit Type Of Package 1 | piece |
|---|---|
| Number Of Units In Package 1 | 1 |
| Package 1 Height | 5 cm |
| Package 1 Width | 6 cm |
| Package 1 Length | 10 cm |
| Package 1 Weight | 0.095 kg |
| Unit Type Of Package 2 | S01 |
| Number Of Units In Package 2 | 14 |
| Package 2 Height | 15 cm |
| Package 2 Width | 15 cm |
| Package 2 Length | 40 cm |
| Package 2 Weight | 1.512 kg |
| Indivisible Sale Quantity | 1 |
