Telemecanique Sensors
XUYFNEP40050 - F 40 050 COS PHOTOELECTRIC SENSOR FORK
Telemecanique Sensors XUYFNEP40050, F 40 050 COS PHOTOELECTRIC SENSOR FORK. Request a quote for price and lead time.
- Reference:XUYFNEP40050
- Manufacturer / Brand:Telemecanique Sensors
- Availability:On Request / Inquire Stock
- Price:228.00 EUR (Request a quote)
Key Specifications
- Range Of Product
- Telemecanique Photoelectric sensors XU
- Sensor Name
- XUY
- Series Name
- Application
- Enclosure Material
- Painted aluminium and polyamide/glass
Product Description
Telemecanique Sensors XUYFNEP40050 (F 40 050 COS PHOTOELECTRIC SENSOR FORK). Ask UC-EL Electric for a quote with the current price, stock and delivery details.
Technical Specifications
Main17
| Range Of Product | Telemecanique Photoelectric sensors XU |
|---|---|
| Sensor Name | XUY |
| Series Name | Application |
| Product Specific Application | Detection of double sheet, detection of labels, detection of reference marks, detection on small conveyor, detection on vibrating rail |
| Enclosure Material | Painted aluminium and polyamide/glass |
| Electronic Sensor Type | Photo-electric sensor |
| Sensor Design | Fork |
| Material | Metal/plastic |
| Electrical Connection | 1 male connector M8, 4 pins |
| Wiring Technique | 4-wire |
| Detection System | Thru beam |
| Emission | Infrared LED, modulated |
| Discrete Output Function | 1 NO or 1 NC programmable |
| [Us] Rated Supply Voltage | 12...24 V DC with reverse polarity protection |
| Type Of Output Signal | Discrete |
| Supply Circuit Type | DC |
| Discrete Output Type | PNP and NPN |
Complementary6
| Setting-up | Sensitivity by numeric potentiometer |
|---|---|
| Current Consumption | 40 mA no-load |
| Status LED | Adjustment mode and keypad locking: 1 LED (red), output state: 1 LED (yellow) |
| Output Type | Solid state |
| Switching Capacity In MA | 100 mA (overload and short-circuit protection) |
| Voltage Drop | <2 V (closed state) |
Environment3
| Shock Resistance | 30 gn (duration = 11 ms) conforming to IEC 60068-2-27 |
|---|---|
| IP Degree Of Protection | IP65 conforming to IEC 60529 |
| Vibration Resistance | 7 gn, amplitude = +/- 0.75 mm (f = 10-55 Hz) conforming to IEC 60068-2-6 |
Offer Sustainability1
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
|---|
Packing Units18
| Unit Type Of Package 1 | piece |
|---|---|
| Number Of Units In Package 1 | 1 |
| Package 1 Height | 1.8 cm |
| Package 1 Width | 12.8 cm |
| Package 1 Length | 16 cm |
| Package 1 Weight | 0.074 kg |
| Unit Type Of Package 2 | S01 |
| Number Of Units In Package 2 | 12 |
| Package 2 Height | 15 cm |
| Package 2 Width | 15 cm |
| Package 2 Length | 40 cm |
| Package 2 Weight | 1.064 kg |
| Unit Type Of Package 3 | S02 |
| Number Of Units In Package 3 | 20 |
| Package 3 Height | 15 cm |
| Package 3 Width | 30 cm |
| Package 3 Length | 40 cm |
| Indivisible Sale Quantity | 1 |
