Telemecanique Sensors
Latching emergency stop rope pull switch XY2CH, 1NC+1NO, key release pushbutton, cable 15 m
Telemecanique Sensors XY2CH13450, Latching emergency stop rope pull switch XY2CH, 1NC+1NO, key release pushbutton, cable 15 m. Category: Standard size - up to 30 m. In stock.
- Reference:XY2CH13450
- Manufacturer / Brand:Telemecanique Sensors
- Availability:In stock (1 pcs) ✅
- Price:261.00 EUR (Request a quote)
Key Specifications
- Product Or Component Type
- Latching emergency stop rope pull switch
- Device Short Name
- XY2CH
- Housing Colour
- Red RAL 3000
Product Description
The Telemecanique Sensors XY2CH13450 reference product is a latching emergency stop rope pull switch from the Preventa XY2 series. Featuring 1 NC + 1 NO contact arrangement and key release pushbutton reset, this model is built with a zamak body and stainless steel cover. You can obtain information and request a quote for this product through UC-EL Electric.
Technical Specifications
Main5
| Range Of Product | Telemecanique Emergency stop rope pull switches XY2C |
|---|---|
| Product Or Component Type | Latching emergency stop rope pull switch |
| Device Short Name | XY2CH |
| Housing Colour | Red RAL 3000 |
| Overvoltage Category | Class I conforming to IEC 61140, class I conforming to NF C 20-030 |
Complementary16
| Local Signalling | Without pilot light |
|---|---|
| Body Material | Zamak |
| Cover Material | Stainless steel |
| Reset | By key-release push-button |
| Key Number | 421 |
| Contacts Type And Composition | 1 NC + 1 NO |
| Contact Operation | Slow-break |
| Trigger Cable Anchor Point | RH or LH side |
| Connections - Terminals | Screw clamp terminal, 1 x 0.5...2 x 1.5 mm² |
| Safety Level | Can reach PL = e with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1, can reach category 4 with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1, can reach SIL 3 with the appropriate monitoring system and correctly wired conforming to EN/IEC 61508 |
| Safety Reliability Data | B10d = 4000000 conforming to IEC 60947-5-5 value given for a life time of 20 years limited by mechanical or contact wear |
| Marking | CE |
| Positive Opening | With conforming to IEC 60947-5-1 |
| Resistance Across Terminals | 25 MOhm conforming to IEC 60255-7 category 3, 25 MOhm conforming to NF C 93-050 method A |
| Terminals Description ISO N°1 | (13-14)NO, (21-22)NC |
| Compatibility Code | XY2CH |
Environment6
| Standards | IEC 60204-1, IEC 60947-5-1, IEC 60947-5-5, ISO 13850, machinery directive 2006/42/EC, work equipment directive 2009/104/EC |
|---|---|
| Product Certifications | UL category NISD emergency stop devices, CCC |
| Protective Treatment | TC |
| Vibration Resistance | 10 gn (f= 10-150 Hz) conforming to IEC 60068-2-6 |
| Shock Resistance | 50 gn 11 ms conforming to IEC 60068-2-27 |
| IP Degree Of Protection | IP65 conforming to IEC 60529 |
Packing Units19
| Unit Type Of Package 1 | piece |
|---|---|
| Number Of Units In Package 1 | 1 |
| Package 1 Height | 9.1 cm |
| Package 1 Width | 8 cm |
| Package 1 Length | 19.5 cm |
| Package 1 Weight | 1.052 kg |
| Unit Type Of Package 2 | S03 |
| Number Of Units In Package 2 | 10 |
| Package 2 Height | 30 cm |
| Package 2 Width | 30 cm |
| Package 2 Length | 40 cm |
| Package 2 Weight | 11.049 kg |
| Unit Type Of Package 3 | carton |
| Number Of Units In Package 3 | 1 |
| Package 3 Height | 19.5 cm |
| Package 3 Width | 9.1 cm |
| Package 3 Length | 8 cm |
| Package 3 Weight | 1.095 kg |
| Indivisible Sale Quantity | 1 |
Offer Sustainability1
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
|---|
Documents and Downloads
Documents are published by the manufacturer and open in a new tab.
Datasheets1
Catalogues2
Instructions4
Environmental Information3
Declarations4
- XY2CE1/2/5/6..., XY2CED... and XY2CH1... emergency stop trip wire switches - EC/EU declaration of conformityOpens in a new tab
- XY2CE1/2/5/6..., XY2CED... and XY2CH1... emergency stop trip wire switches - UK declaration of conformityOpens in a new tab
- XY2CH1... emergency stop trip wire switches - EC/EU declaration of conformityOpens in a new tab
- XY2CH1... emergency stop trip wire switches - UK declaration of conformityOpens in a new tab
