Telemecanique Sensors
ZCKS404 - LIMIT SWITCH
Telemecanique Sensors ZCKS404, LIMIT SWITCH. Category: Standard size - up to 70 m. Request a quote for price and lead time.
- Reference:ZCKS404
- Manufacturer / Brand:Telemecanique Sensors
- Availability:On Request / Inquire Stock
- Price:158.00 EUR (Request a quote)
Key Specifications
- Range Of Product
- Telemecanique Limit switches XC Standard
- Series Name
- Standard format
- Product Or Component Type
- Limit switch body with spring return rotary head
- Device Short Name
- ZCKS
Product Description
Telemecanique Sensors ZCKS404 (LIMIT SWITCH). Ask UC-EL Electric for a quote with the current price, stock and delivery details.
Technical Specifications
Main11
| Range Of Product | Telemecanique Limit switches XC Standard |
|---|---|
| Series Name | Standard format |
| Product Or Component Type | Limit switch body with spring return rotary head |
| Device Short Name | ZCKS |
| Body Type | Fixed |
| Product Compatibility | XCKS |
| Body Material | Plastic |
| Cable Entry | 1 entry tapped for Pg 13.5 cable gland |
| Contacts Type And Composition | 2 C/O |
| Contact Operation | Snap action |
| Contacts Material | Silver plated contacts |
Complementary5
| Switch Actuation | From left and right |
|---|---|
| Electrical Connection | Screw-clamp terminals, clamping capacity: 1 x 0.75...2 x 1.5 mm² |
| Positive Opening | Without |
| Resistance Across Terminals | 0.25 mOhm conforming to IEC 60255-7 category 3 |
| Terminals Description ISO N°1 | (13-14)NO, (23-24)NO |
Environment3
| IP Degree Of Protection | IP65 |
|---|---|
| IK Degree Of Protection | IK03 |
| Environmental Characteristic | Standard environment |
Offer Sustainability1
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
|---|
Packing Units13
| Unit Type Of Package 1 | piece |
|---|---|
| Number Of Units In Package 1 | 1 |
| Package 1 Height | 6 cm |
| Package 1 Width | 7.2 cm |
| Package 1 Length | 12 cm |
| Package 1 Weight | 0.164 kg |
| Unit Type Of Package 2 | S02 |
| Number Of Units In Package 2 | 20 |
| Package 2 Height | 15 cm |
| Package 2 Width | 30 cm |
| Package 2 Length | 40 cm |
| Package 2 Weight | 3.591 kg |
| Indivisible Sale Quantity | 1 |
Documents and Downloads
Documents are published by the manufacturer and open in a new tab.
Datasheets1
Catalogues2
Environmental Information3
Declarations3
CAD Drawings3
- double insulated\adaptable sub-assemblies\body/contact assemblies with spring return rotary head, 2 steps (dwf)Opens in a new tab
- double insulated\adaptable sub-assemblies\body/contact assemblies with spring return rotary head, 2 steps (dwf)Opens in a new tab
- double insulated\adaptable sub-assemblies\body/contact assemblies with spring return rotary head, 2 steps (wmf)Opens in a new tab
