Telemecanique Sensors
ZCMD41L5 - LS MET BODY 2NC2NO SA 5M 9 CONDUCTORS
Telemecanique Sensors ZCMD41L5, LS MET BODY 2NC2NO SA 5M 9 CONDUCTORS. Request a quote for price and lead time.
- Reference:ZCMD41L5
- Manufacturer / Brand:Telemecanique Sensors
- Availability:On Request / Inquire Stock
- Price:95.00 EUR (Request a quote)
Key Specifications
- Range Of Product
- Telemecanique Limit switches XC Standard
- Series Name
- Standard format
- Product Or Component Type
- Limit switch body
- Device Short Name
- ZCMD
Product Description
Telemecanique Sensors ZCMD41L5 (LS MET BODY 2NC2NO SA 5M 9 CONDUCTORS). Ask UC-EL Electric for a quote with the current price, stock and delivery details.
Technical Specifications
Main9
| Range Of Product | Telemecanique Limit switches XC Standard |
|---|---|
| Series Name | Standard format |
| Product Or Component Type | Limit switch body |
| Device Short Name | ZCMD |
| Design | Miniature |
| Body Type | Fixed |
| Body Material | Zamak |
| Contacts Type And Composition | 2 NC + 2 NO |
| Contact Operation | Snap action |
Complementary8
| Product Compatibility | XCMD |
|---|---|
| Electrical Connection | Fixed cable |
| Cable Composition | 9 x 0.34 mm² |
| Contacts Insulation Form | Zb |
| Wire Insulation Material | PvR |
| Contacts Material | Silver plated contacts |
| Positive Opening | With |
| Resistance Across Terminals | 25 mOhm conforming to IEC 60255-7 category 3 |
Offer Sustainability1
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
|---|
Packing Units19
| Unit Type Of Package 1 | piece |
|---|---|
| Number Of Units In Package 1 | 1 |
| Package 1 Height | 3 cm |
| Package 1 Width | 18.5 cm |
| Package 1 Length | 20 cm |
| Package 1 Weight | 0.462 kg |
| Unit Type Of Package 2 | S03 |
| Number Of Units In Package 2 | 20 |
| Package 2 Height | 30 cm |
| Package 2 Width | 40 cm |
| Package 2 Length | 30 cm |
| Package 2 Weight | 8.928 kg |
| Unit Type Of Package 3 | BAG |
| Number Of Units In Package 3 | 1 |
| Package 3 Height | 3 cm |
| Package 3 Width | 20 cm |
| Package 3 Length | 18.5 cm |
| Package 3 Weight | 0.475 kg |
| Indivisible Sale Quantity | 1 |
Documents and Downloads
Documents are published by the manufacturer and open in a new tab.
Datasheets1
Catalogues2
Leaflets2
Environmental Information3
Declarations3
CAD Drawings6
- Bodies with gold contact with XCM D cable (dwg)Opens in a new tab
- Bodies with gold contact with XCM D cable (eps)Opens in a new tab
- Bodies with gold contact with XCM D cable (dwf)Opens in a new tab
- Limit switches OsiSense XC, miniature 30*50*16 type XCM, sub assembly body with precabled connector - 3D CAD (dxf)Opens in a new tab
- Limit switches OsiSense XC, miniature 30*50*16 type XCM, sub assembly body with precabled connector - 3D CAD (dwg)Opens in a new tab
- Limit switches OsiSense XC, miniature 30*50*16 type XCM, sub assembly body with precabled connector - 3D CAD (dxf)Opens in a new tab
